Flat Cables

Flat Cables
Flat Cables
Product Code : 1298
Brand Name : HAVELLS
Product Description

Flat Cables

Three Core Flat PVC Insulated Flexible Industrial Cable for Submersible use, 1100 Voltage Grade



Technical Information

Basic Code Nominal area of conductor INSULATION SHEATH Approx Overall Dimension Max Conductor Resistance at 20°C (Max.) Current Carrying Capacity at 40°C
*Number/ Size of Wire for each Core Thickness (Nom.) Core dia. (Nom.) Width Height
sq mm mm mm mm (Nom.) mm (Nom.) mm Ohm/Km Amps.
WHPNDSKB 31X5 1.50 30/0.25 0.6 2.8 10.1 4.7 13.3 13
WHPNDSKB 32X5 2.50 50/0.25 0.7 3.5 12.2 5.5 7.98 18
WHPNDSKB 34X0 4.00 56/0.30 0.8 4.2 14.6 6.5 4.95 24
WHPNDSKB 36X5 6.00 84/0.30 0.8 4.7 16.2 7.0 3.30 31
WHPNDSKB 3010 10.00 80/0.40 1.0 6.0 20.2 8.5 1.91 42
WHPNDSKB 3016 16.00 126/0.40 1.0 7.0 23.4 9.7 1.21 57
WHPNDSKB 3025 25.00 196/0.40 1.2 8.6 28.5 11.7 0.780 72
WHPNDSKB 3035 35.00 276/0.40 1.2 9.7 32.1 13.0 0.554 90

Note: Available in 500 ± 5% metres packing in drums. Also available in 100 metres packing on request.
*The number and diameter of conductor strands are for reference only. Conductor resistance as per IS:8130 is the governing criteria.
Conductor shall be of Class-V as per IS:8130
